Full specifications

Reference

L342I7TGE8256W11D1WXCTO

Release date

12-2021, 1 year ago

Design

Product type

Notebook

Product color

Gray

Form factor

Clamshell

Market positioning

Business

Display

Display diagonal

14 " (35,6 cm)

Display resolution

1366 x 768 pixels

Touchscreen

No

HD type

HD

Panel type

TN

LED backlight

Yes

Native aspect ratio

16:9

Anti-glare screen

Yes

Display brightness

220 cd/m²

Pixel pitch

0,22 x 0,22 mm

Pixel density

112 ppi

RGB color space

NTSC

Color gamut

45 %

Display response rise/fall

25 ms

Maximum refresh rate

60 Hz

Contrast ratio (typical)

300:1

Processor

Processor family

Intel® Core™ i7

Processor manufacturer

Intel

Processor model

i7-1165G7

Generación del procesador

Intel Core i7-11xxx

Processor boost frequency

4,7 GHz

Processor cores

4

Processor cache

12 MB

Configurable TDP-up frequency

2,8 GHz

Configurable TDP-up

28 W

Configurable TDP-down

12 W

Configurable TDP-down frequency

1,2 GHz

Memory

Internal memory

8 GB

Maximum internal memory

32 GB

Internal memory type

DDR4-SDRAM

Memory clock speed

3200 MHz

Memory form factor

SO-DIMM

Memory layout (slots x size)

1 x 8 GB

Memory slots

2x SO-DIMM

ECC

No

Storage

Total storage capacity

256 GB

Storage media

SSD

Optical drive type

No

Total SSDs capacity

256 GB

Number of SSDs installed

1

SSD capacity

256 GB

SSD interface

NVMe,PCI Express

NVMe

Yes

SSD form factor

M.2

Card reader integrated

Yes

Compatible memory cards

MicroSD (TransFlash),MicroSDHC,MicroSDXC

Graphics

On-board graphics card

Yes

Discrete graphics card

No

Discrete graphics card model

Not available

On-board graphics card model

Intel Iris Xe Graphics

Audio

Audio chip

Realtek ALC3204

Number of built-in speakers

2

Speaker power

2 W

Built-in microphone

Yes

Camera

Front camera

Yes

Front camera resolution (numeric)

0,92 MP

Front camera resolution

1280 x 720 pixels

Front camera HD type

HD

Video capturing speed

30 fps

Network

Mobile network connection

No

Top Wi-Fi standard

Wi-Fi 6 (802.11ax)

Wi-Fi standards

802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax)

Wi-Fi data rate (max)

2400 Mbit/s

Antenna type

2x2

WLAN controller model

Intel Wi-Fi 6 AX201

WLAN controller manufacturer

Intel

Ethernet LAN

Yes

Ethernet LAN data rates

10,100,1000 Mbit/s

Bluetooth

Yes

Bluetooth version

5.1

Ports & interfaces

USB 2.0 ports quantity

1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2

HDMI ports quantity

1

USB 3.2 Gen 2x2 Type-C ports quantity

1

Ethernet LAN (RJ-45) ports

1

HDMI version

1.4a

Combo headphone/mic port

Yes

USB Type-C DisplayPort Alternate Mode

Yes

USB Power Delivery

Yes

PowerShare

Yes

Number of USB ports with PowerShare support

1

Keyboard

Numeric keypad

No

Pointing device

SinglePoint

Keyboard language

Spanish

Software

Operating system installed

Windows 10 Pro

Operating system architecture

64-bit

Actualización de Windows 11 gratuita

Yes

Operating system language

ENG,ESP,FRE

Trial software

Microsoft Office 30 Day Trial

Processor special features

Intel Trusted Execution Technology

No

Intel VT-x with Extended Page Tables (EPT)

Yes

Intel Stable Image Platform Program (SIPP)

No

Intel Software Guard Extensions (Intel SGX)

No

Idle States

Yes

CPU configuration (max)

1

Embedded options available

No

Intel Virtualization Technology for Directed I/O (VT-d)

Yes

Intel Virtualization Technology (VT-x)

Yes

Battery

Battery capacity

41 Wh

Number of battery cells

3

Battery voltage

11,25 V

Battery recharge time

4 h

Fast charging

Yes

Battery weight

6 oz (170 g)

Power

AC adapter power

65 W

AC adapter frequency

50/60 Hz

AC adapter input voltage

100 - 240 V

Security

Cable lock slot

Yes

Password protection

Yes

Operational conditions

Operating temperature (T-T)

0 - 35 °C

Storage temperature (T-T)

-40 - 65 °C

Operating relative humidity (H-H)

10 - 90 %

Storage relative humidity (H-H)

0 - 95 %

Operating altitude

-15,2 - 3048 m

Non-operating altitude

-15,2 - 10668 m

Operating shock

3.9 oz (110 G)

Non-operating shock

5.6 oz (160 G)

Operating vibration

0 oz (0,66 G)

Non-operating vibration

0 oz (1,3 G)

Weight & dimensions

Weight

3.4 lbs (1,52 kg)

Width

12.8 " (326 mm)

Depth

8.9 " (226 mm)

Height (front)

0.7 " (1,76 cm)

Height (rear)

0.7 " (1,76 cm)
